ATMEGA8L-8PU

Microcontroller, DIP-28, 16MHz

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.98~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.98~1.20

PartNumber:: ATMEGA8L-8PU

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Thomas's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-24

From Other Seller

Part Number:ATMEGA8L-8PU
US $0.98 - 1.20
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
MOC3063

US $0.32 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ATMEGA8L-8PU is a low-power CMOS 8-bit microcontroller based on the AVR RISC architecture. By executing powerful structions in a single clock cycle, the ATMEGA8L-8PU achieves throughputs approaching 1 MIPS per MHz, allowing the system designer to optimize power consumption versus processing speed.

Parametrics

ATMEGA8L-8PU absolute maximum ratings: (1)Operating Voltages: 2.7V - 5.5V ; (2)Speed Grades: 0 - 8MHz ; (3)Power Consumption at 4Mhz, 3V, 25℃; (4)Active: 3.6mA; (5)Idle Mode: 1.0mA; (6)Power-down Mode: 0.5μA.

Features

ATMEGA8L-8PU features: (1)High-performance, Low-power Atmel AVR 8-bit Microcontroller; (2)Advanced RISC Architecture; (3)130 Powerful Instructions-Most Single-clock Cycle Execution; (4)32*8 General Purpose Working Registers; (5)Fully Static Operation; (6)Up to 16 MIPS Throughput at 16MHz; (7)On-chip 2-cycle Multiplier; (8)High Endurance Non-volatile Memory segments; (9)8Kbytes of In-System Self-programmable Flash program memory; (10)512Bytes EEPROM; (11)1Kbyte Internal SRAM; (12)Write/Erase Cycles: 10,000 Flash/100,000 EEPROM; (13)Optional Boot Code Section with Independent Lock Bits; (14)In-System Programming by On-chip Boot Program; (15)True Read-While-Write Operation; (16)Programming Lock for Software Security; (17)Peripheral Features; (18)Two 8-bit Timer/Counters with Separate Prescaler, one Compare Mode; (19)One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture; (20)Mode; (21)Real Time Counter with Separate Oscillator; (22)Three PWM Channels; (23)8-channel ADC in TQFP and QFN/MLF package; (24)Eight Channels 10-bit Accuracy; (25)6-channel ADC in PDIP package; (26)Six Channels 10-bit Accuracy; (27)Byte-oriented Two-wire Serial Interface; (28)Programmable Serial USART; (29)Master/Slave SPI Serial Interface.
