MAX6675ISA+T

SOP-8, K-Thermocoupleto-Digital Converter, Cold-Junction-Compensated

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.95~3.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.95~3.50

PartNumber:: MAX6675ISA+T

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Thomas's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-21

From Other Seller

Part Number:MAX6675ISA+T
US $2.95 - 3.50
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX6675ISA+T performs cold-junction compensation and digitizes the signal from a type-K thermocouple. The data is output in a 12-bit resolution, SPI-compatible, read-only format. This converter resolves temperatures to 0.25℃, allows readings as high as +1024℃, and exhibits thermocouple accuracy of 8LSBs for temperatures ranging from 0℃ to +700℃. The MAX6675ISA+T is available in a small, 8-pin SO package.

Parametrics

MAX6675ISA+T absolute maximum ratings: (1)Supply Voltage (VCC to GND): -0.3V to +6V; (2)SO, SCK, CS, T-, T+ to GND: -0.3V to VCC + 0.3V; (3)SO Current: 50mA; (4)ESD Protection (Human Body Model): ±2000V; (5)Continuous Power Dissipation (TA = +70℃); (6)8-Pin SO (derate 5.88mW/℃ above +70℃): 471mW; (7)Operating Temperature Range: -20℃ to +85℃; (8)Storage Temperature Range: -65℃ to +150℃; (9)Junction Temperature: +150℃; (10)SO Package Vapor Phase (60s): +215℃; (11)Infrared (15s): +220℃; (12)Lead Temperature (soldering, 10s): +300℃.

Features

MAX6675ISA+T features: (1)Direct Digital Conversion of Type -K Thermocouple Output; (2)Cold-Junction Compensation; (3)Simple SPI-Compatible Serial Interface; (4)12-Bit, 0.25℃ Resolution; (5)Open Thermocouple Detection.
